- General Information
- Manufacturer
- Enermax
- Manufacturer Website Address
- http://www.enermax.com.br
- Brand Name
- Enermax
- Product Line
- Platimax
- Product Type
- Power Supply
89 PLUS ready!
World's leading modular cable PSU series with 89-94% efficiency @ 20-100% load. Compliant with 80PLUS® PLATINUM efficiency requirement.
FMQ Design
Fully utilize transformer's quad magnetic quadrants energy to provide maximum switching efficiency and outstanding stability
Extreme Density Transformer
Innovative design boosts transformer core utilization rate and reduce overall dimension
- Extreme power density performance
- 50% space saving than conventional design
- Excellent heat dissipation
- Low air resistance and less air friction noise
Advanced +5Vsb circuitry with up to 20% improved efficiency in comparison to generic designs helps your system meet ErP Lot 6 2013 ( AC < 0.5W at standby) requirement.
Modular ready!
Full modular cable design for easy customized support for various peripheral settings.
Enhanced Heatsink
Unique one-piece shape design ensures uniform heat distribution and increases air flow
- Technical Information
- Specification Compliance
- ATX12V/EPS12V
- Efficiency
- 94%
- Number of Fans
- 1
- Modular
- Yes
- ATI CrossFire Supported
- Yes
- NVIDIA SLI Supported
- Yes
- Power Description
- Number of +12V Rails
- 6
- Input Voltage
- 120 V AC
- 230 V AC
- Output Voltage
- 3.3 V DC
- 5 V DC
- 12 V DC
- -12 V DC
- Output Voltage Detail
- 3.3 V DC @ 24 A
- 5 V DC @ 24 A
- 12 V DC @ 30 A
- -12 V DC @ 0.5 A
- 5 V DC @ 3 A
- Output Current
- 24 A
- 30 A
- 500 mA
- 3 A
- Physical Characteristics
- Form Factor
- Internal
- Height
- 3.4"
- Width
- 5.9"
- Depth
- 7.1"
