- Processor & Chipset
- Chipset Manufacturer
- AMD
- Chipset Model
- B550
- Processor Socket
- Socket AM4
- Processor Supported
- Ryzen 5
- Ryzen 3
- Memory
- Number of Memory Slots
- 4
- Maximum Memory Supported
- 128 GB
- Memory Technology
- DDR4 SDRAM
- Memory Speed Supported
- 4400 MHz
- 4266 MHz
- 4133 MHz
- 4000 MHz
- 3866 MHz
- 3733 MHz
- 3600 MHz
- 3466 MHz
- 3200 MHz
- 3066 MHz
- 3000 MHz
- 2933 MHz
- 2800 MHz
- 2667 MHz
- 2400 MHz
- 2133 MHz
- 1866 MHz
- Error Checking
- ECC
- I/O Controller
- RAID Supported
- Yes
- RAID Levels
- 0
- 1
- 10
- Video
- Onboard Video
- CPU Dependent Video
- Audio
- Audio Channels
- 7.1
- Network & Communication
- Bluetooth
- Yes
- Bluetooth Standard
- Bluetooth 5.2
- Gigabit Ethernet
- Yes
- Wireless LAN
- Yes
- Wireless LAN Standard
- IEEE 802.11ax
- I/O Expansions
- Total Number of Expansion Slots
- 4
- PCI Express Standard
- PCI Express 4.0
- PCI Express 3.0
- Total Number of PCI Express Slots
- 4
- Number of PCI Express x16 Slots
- 4
- Interfaces/Ports
- Total Number of USB Ports
- 6
- Number of USB 3.2 Gen 1 Type-A Ports
- 2
- Number of USB 3.2 Gen 2 Type-A Ports
- 2
- VGA
- Yes
- HDMI
- Yes
- DisplayPort
- Yes
- Number of Network (RJ-45) Ports
- 1
- Thunderbolt
- No
- Onboard Interfaces
- Number of M.2 Interfaces
- 2
- Total Number of Onboard USB Ports
- 7
- Number of Onboard USB 2.0 Ports
- 4
- Physical Characteristics
- Form Factor
- Micro ATX
- Width
- 9.6"
- Depth
- 9.6"
