- General Information
- Manufacturer
- SilverStone Technology, Inc
- Manufacturer Website Address
- http://www.silverstonetek.com
- Brand Name
- SilverStone
- Product Line
- Essential
- Product Type
- Power Supply
Designed for 80 PLUS Gold level of efficiency to reduce wasted heat and save on electricity
Powerful single +12V rail design, perfect for future high-end component upgrades or overclocking
Built-in 120 mm fan has excellent airflow and low noise, perfect for quiet home or office use
Advanced protections for safety and security
- Over current protection
- Over power protection
- Over voltage protection
- Short circuit protection
- Over temperature protection
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Efficiency
- 90%
- Power Factor Correction (PFC)
- Active
- Number of Fans
- 1
- Fan Diameter
- 120 mm
- Protection Type
- Over Current
- Over Power
- Over Voltage
- Over Temperature
- Short Circuit
- Reliability
- MTBF
- 100000 Hour
- Power Description
- Number of +12V Rails
- 1
- Input Voltage
- 120 V AC
- 230 V AC
- Output Voltage
- 3.3 V DC
- 5 V DC
- 12 V DC
- -12 V DC
- 5 V SB
- Output Voltage Detail
- 5 V SB @ 2.5 A
- -12 V DC @ 0.3 A
- 3.3 V DC @ 20 A
- 5 V DC @ 20 A
- 12 V DC @ 42 A
- Output Power
- 550 W
- Input Frequency
- 63Hz
- Interfaces/Ports
- Number of SATA Power Connectors
- 8
- PCI Express Connector
- Yes
- Number of (6+2 pin) PCI Express Power Connectors
- 2
- Number of (4+4 pin) CPU Power Connectors
- 1
- Environmental Conditions
- Minimum Operating Temperature
- 32°F (0°C)
- Maximum Operating Temperature
- 104°F (40°C)
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Form Factor
- ATX
- Height
- 3.4"
- Width
- 5.9"
- Depth
- 5.5"
- Weight (Approximate)
- 3.40 lb
- Miscellaneous
- Certifications & Standards
- CE
- FCC
- TUV
- Country of Origin
- China
- Energy Efficiency Certification
- 80 Plus Gold
- Environmental Compliance
- China Restriction of Hazardous Substances (China RoHS)
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
