- General Information
- Manufacturer
- Tyan Computer Corp
- Manufacturer Website Address
- http://www.tyan.com
- Brand Name
- Mitac
- Product Line
- Tomcat
- Packaged Quantity
- 1
- Product Type
- Workstation Motherboard
- Processor & Chipset
- Chipset Manufacturer
- AMD
- Total Processor Supported
- 1
- Processor Socket
- Socket SP3
- Processor Supported
- EPYC
- Memory
- Number of Memory Slots
- 8
- Memory Form Factor
- RDIMM
- LRDIMM
- Maximum Memory Supported
- 2 TB
- Memory Technology
- DDR4 SDRAM
- Memory Speed Supported
- 3200 MHz
- I/O Controller
- Controller Type
- Serial ATA/600
- RAID Supported
- No
- Video
- Onboard Video
- On-board Video Chipset
- Graphics Controller Model
- AST2500
- Network & Communication
- Gigabit Ethernet
- Yes
- I/O Expansions
- Total Number of Expansion Slots
- 5
- Total Number of PCI Express Slots
- 5
- Number of PCI Express x16 Slots
- 5
- Interfaces/Ports
- Total Number of USB Ports
- 2
- Number of USB 3.1 Ports
- 2
- VGA
- Yes
- Number of Network (RJ-45) Ports
- 2
- Onboard Interfaces
- Number of SATA Interfaces
- 14
- Number of M.2 Interfaces
- 2
- Physical Characteristics
- Form Factor
- ATX
- Width
- 12"
- Depth
- 9.9"
- Miscellaneous
- Package Contents
- Tomcat HX S8030
- 1 x Quick Installation Guide
- 1 x I/O Shield
- 2 x SATA signal Cables
- Country of Origin
- China
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- China Restriction of Hazardous Substances (China RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
